Winston

Winston Larger RightBased on an original design the Winston Lantern has been modernised to incorporate a whole array of control gears, light sources and communication systems thus giving you an original design which meets the demands of today’s modern society.

Key Features

Manufactured in spun aluminium and stainless steel
UV stable polycarbonate glazing
Various optical options and lamp types
High resistance to vandalism, low maintenance
10-year structural guarantee with all IP66 rated lanterns
Available in full range of RAL and BS polyester powder coated paint finishes

Winston Small Pic






Photometry
DXF drawing file

Lantern Sizes

Max Height (A) Max Width (B) Mounting Height Weight Windage
3) 809mm 720mm 7m-8.5m 13.5kg 0.25m²
4) 700mm 600mm 5m-6.5m 11.5kg 0.18m²
5) 500mm 415mm 2.5m-4m 10kg 0.10m²

Winston Range



Fixing Options

Lantern Size BSP Conduit Quick Mount
3 1¼" BSP Standard
4 1" BSP Standard
5 0.5" BSP n/a

Winston Fixing Options



Light Sources & Reflectors

Size CPO MH HPS PL LED
3 45w - 140w 50w - 250w 50w - 250w 11w - 57w 1100 - 6000lm
4 45w - 140w 50w - 150w 50w - 150w 11w - 57w 1100 - 6000lm
5 50w - 70w 50w - 70w 11w - 42w 470 - 1055lm

Key

CPO Cosmopolis
MH Metal Halide
HPS High Pressure Sodium (SON)
PL Compact Fluorescent
LED Light Emitting Diode


Lighting Reflectors
> Metcraft MPO - 5 Positions
> Metcraft MPR - 5 Positions
> Philips SGS 203 pot optic - 3 Positions
> Refractor

Photometric data available, see download section above

Control Gears & Systems

Gear
> Magnetic gear
> Electronic ballasts
Smart ballasts

Switching
> Photocells
> Part night cells

Management Systems
> 1-10v
> Dali
> Wimac

Click here for further information on Electronic Controls
Click here for further information on Management Systems

Columns & Brackets

Click here for more examples of columns
Click here for more examples of brackets

Winston Brackets & Columns
